Allied Vision GT/GX cameras affected by ON Semiconductor CCD Sensor discontinuation

The rapid move from CCD image sensors to CMOS has unfortunately accelerated the discontinuation of several popular camera series. While this creates issues for existing products using these cameras, it is not all bad news as CMOS image sensors outperform CCD’s and have lowered overall camera prices.

Allied Vision Prosilica GT and GX camera models using ON Semiconductor (formerly Kodak) KAI series sensors are being affected and going end of life. However, Allied Vision has already moved quickly to support customers affected with the discontinuation by introducing several new models with resolutions from 16.8 to 31.4 Megapixels using IMX367, IMX387 and IMX342 sensors. In many cases, there is not a 100% drop in replacement, but by consulting with an imaging advisor, we can help identify some options.
Contact us with your current model for support and recommendations.

The discontinuation is being forced by ON Semiconductor announcing the discontinuation of its CCD sensors and subsequent closure of its Rochester NY plant. (here is the original announcement) This affects all cameras using these sensors!

What camera models are effected by ON Semiconductors discontinuation?


All ON Semiconductors (previously Kodak) image sensors starting with KAI will be effected. The various image sensor models are listed in the above announcement and the associated Allied Vision’s popular Prosilica GT and GX models effected is listed below.

Allied Vision Prosilica GT & GX models effected are in an immediate discontinuation with last time purchases through 3/2/2020. We are encouraging customers to place orders if they are needing spares for field replacements or have immediate builds upcoming. Pricing has increased already 25% due to immediate sensor increases and will increase again December 15, 2019! Click on your model for a quote prior to more price increases.

For Quotes on Prosilica GT cameras click HERE

For Quotes on Prosilica GX cameras click HERE

1stVision can provide suggestions to aid in the transition of cameras. If you have specific models being used, please use our contact form and complete the model’s used and we will contact you with various options.

Contact us to discuss
camera replacement options

1st Vision’s sales engineers have over 100 years of combined experience to assist in your camera selection.  With a large portfolio of lenses, cables, NIC card and industrial computers, we can provide a full vision solution!

Ph:  978-474-0044  /  info@1stvision.com  / www.1stvision.com

What is a “TECless” SWIR camera? Learn more about Allied Vision’s highly cost-effective SWIR camera models

SWIR camera

Allied Vision Goldeye SWIR cameraShort Wave Infra-Red (SWIR) imaging is now more economical with the introduction of Allied Vision’s TECless Goldeye cameras.  SWIR cameras open up numerous application possibilities for machine vision solutions, since they are able to detect defects that are not visible to the naked eye.

SWIR cameras have an InGaAs (Indium Gallium Arsenide) sensor that detects wavelengths between 900nm and 1,700nm.  These wavelengths are invisible to the human eye and CCD / CMOS cameras, however SWIR cameras detect the invisible wavelength found in various applications.  For example water accumulations inside fruits or defects within silicon products.

SWIR - light emmission at 1150nm
Light emitted by silicon in solar cells peak at 1150nm

Learn more about applications solved with SWIR cameras HERE.

SWIR cameras typically require Thermal Electric Coolers (TEC’s) which enable low-noise imaging in the spectral range of 900mm to 1,700nm.  Additionally, the TEC’s compensate for high temperature fluctuations and stabilizes the image sensor.
For temperature stable environments, Allied Vision now has a “TECless” InGaAs camera providing a lower entry price point, in turn an excellent price-performance ratio.
The Goldeye G-033 and CL-033 TECless InGaAs cameras are the solution to applications unachievable with standard cameras offering the following features
  • SWIR imaging from 900nm to 1700nm
  • High frame rates of 301 fps with VGA resolution
  • Power over Ethernet (PoE)
  • Compact design with no fan
  • Lower cost vs TEC versions
  • GigE and Camera link interfaces.

Click below for the full specifications on the Goldeye  TECless cameras and click “Get Quote” for pricing

GigE – Goldeye G-008 TECless
Camera link – Goldeye CL-008

Need to see it for yourself?  1stVision can provide a demo Goldeye camera to test on your application.  Submit your request for a demo camera by entering “Send me a demo SWIR camera” in the comment box.

Download the comprehensive SWIR application white paper here.

1st Vision’s sales engineers have over 100 years of combined experience to assist in your camera selection.  With a large portfolio of lenses, cables, NIC card and industrial computers, we can provide a full vision solution!

Related Posts

How to select the best SWIR camera for my application and understand applications it can solve.

Download the comprehensive SWIR application white paper.

Learn about CoaXpress and frame rates achievable with Allied Vision’s “Bonito Pro” cameras with CXP-6

Allied Vision Bonito Pro camera

What is  CoaXPress, especially with “CXP-6” capability?

CoaXPress is an established industry standard allowing high speed communications over coaxial cable.  The current version supports bit rates up to 6.25 Gbits/sec over a single coaxial cable.  When used in parallel, two or more coaxial cables can provide incremental speed gains.  The naming convention associated with CoaXPress signify the bit rate as seen in the chart below.   In cases that you see CXP-6 has a bit rate of 6.25 Gb/s.  The 4 x means the number of lanes. Multiply the 2 and you get your total bit rate.

CXP CoaXpress

The new Allied Vision Bonito Pro cameras utilize 4 DIN 1.0/2.3 connectors on a CXP-6 interface (4 lanes) x 6.25Gbits/Sec. This  allows for resolutions of up to 26 megapixels to reach 70 frames per second (fps).  The first two Bonito PRO models (Bonito PRO X-2620 and X-1250) support high resolution with 26.6MP and 12.5MP at 80 and 142 fps respectively.

The Bonito PRO cameras are ideal for a wide range of applications including, 2D/ 3D surface inspection,  high speed printing, PCB & Electronics inspection.

Even faster frame rates can be achieved using the Bonito Pro X1250 (12.5MP) in partial scan mode.  Set to a 768 line height, a rate of 503 fps can be achieved!

Bonito Pro frame rates

The following video’s are good representations of what this relates to in real applications which you can appreciate.

Full specifications for the Allied Vision Bonito Pro cameras can be found HERE, but main features and benefits include:

  • Sensors available in Monochrome (X-1250B) and Color (X-1250C) and extended near-infrared (X1250B NIR ) models
  • On board defect pixel and 2D fixed pattern noise correction for improved image quality
  • Fan-less design for industrial imaging applications.
  • DIN 1.0 / 2.3 CoaXPress connections for secure operation in industrial environments.
  • Single cable solutions using trigger and power over CoaXPress (PoCXP)

contact us1st Vision’s sales engineers have over 100 years of combined experience to assist in your camera selection.  With a large portfolio of lenses, cables, NIC card and industrial computers, we can provide a full vision solution!



UPDATE:  New video of the Bonito Pro detailing the multi-ROI function





The Machine Vision camera “Sleepability factor”!?

machine vision camera

sleepy cameraThe sleepability factor, or how saving $50 on a machine vision camera could cost you thousands!

As an independent machine vision camera distributor, we are asked about the manufacturers we represent.  Out of all them, we have chosen to only carry products from a few machine vision camera and lens companies of which we have not really changed this over the 20 years we have been in business.  Why is this?

These days, there are probably over 30 different camera manufacturers making products for the machine vision marketplace, many using the identical image sensors.  Considering anyone can just put up a web page and start selling, how can a user know which product to purchase?  Are there really any differences?  Should I just purchase on price?  Should I buy from a distributor or from the manufacturer direct?  All great questions, that we will attempt to answer.

The very simple and quick answer is that if you just need to get a image in good light, pretty much any camera from any vendor will do that job.  No matter if it is from a large company or a 2 person startup, when you take the product out of the box, you should see a “good” image.

But if you said, “I want this camera to run 24/7 for the next 5 years, I want to be able to develop complex software to integrate into my machine, I need the image sensor plane to be within a certain tolerance for each machine,” this changes the situation.

IDS imaging camera
IDS Imaging USB3 cameras

The reason we have chosen the camera manufacturers we sell products from is because each of them has a proven track record of reliability.  Each of the companies we represent ships 6 figures of cameras per year.  IDS Imaging for instance ships close to 200,000 cameras per year and has a return rate of under 0.3%.



Allied vision camera
Allied Vision GigE Cameras

Allied Vision was the first company to incorporate the Precision Timing Protocol (PTP) which allows for precise multi camera sync, enabling our clients to not only make sure the application will work, but it doesn’t take years to develop it.







Dalsa line scan cameras
Teledyne Dalsa Line Scan cameras



Teledyne Dalsa, besides being a leader in line scan technology,  has a SDK that has been built upon for over 30 years.





JAI’s prism technology is so good that its competitors actually have JAI

JAI cameras
JAI 3-CMOS Prism camera

manufacture for them.  This isn’t to say there aren’t other camera companies with such characteristics.  There are, and many of the other camera companies have excellent products as well.  It is just that we have chosen these companies, and we have stood with them for 15+ years for good reasons… sleepabilty!

What does this mean to you as a client?  Yes, you can purchase a camera from any vendor, which on a $500 camera, you might even be saving $50 a camera.  If you purchase 100 cameras a year, this adds up to a reasonable savings of $5,000.  But what happens if your machine, which you sell globally, has a camera that fails.  What is the cost of the line going down at your client?  How do you look in your client’s eyes?  What is the cost for you to fix it?

If you had your choice of buying a camera with the same characteristics at roughly the same price, but one company makes 20,000 a year, and the other makes 200,000 a year, which would you choose?  The same is true if you can choose between a company that has offices all over the world, or just in one country.  Or one that has many application engineers to answer your questions, or just one.

We just want to point out that if you are making a purchase on price alone, depending upon your circumstances, it might not really be a savings at all.  In fact, it might actually not only be costing you money, but it might even be costing you your sleep!

Contact us

1st Vision’s sales engineers have over 100 years of combined experience to assist in your camera selection.  With a large portfolio of lenses, cables, NIC card and industrial computers, we can provide a full vision solution!
