Allied Vision fxo532C25GE | fxo532M25GE
The Allied Vision fxo532C25GE (Color) and fxo532M25GE (Monochrome) 25GigE camera features a Sony Pregius S IMX532 1.1" CMOS global shutter sensor with 16.2 megapixel (5328x3040 resolution), maximum 144 frame rate, and a 2.74 µm pixel size.
Allied Vision FXO GigE cameras combine advanced Sony Pregius S sensors with ultra-high-speed Ethernet connectivity to deliver exceptional image quality, fast data transfer, and reliable performance, providing a flexible and scalable imaging platform for next-generation machine vision systems. These GigE Vision and GenICam compliant FXO cameras are available with 10GigE, 25GigE, or 100GigE interfaces, and color, monochrome, or SWIR configurations.
FXO 10GigE, 25GigE & 100GigE Cameras Features
fxo532C25GE - fxo532M25GE Camera Features
fxo532C25GE (Color) Datasheet
fxo532M25GE (B&W) Datasheet
fxo532C25GE - fxo532M25GE Manual
Sensor Spec
| Manufacturer: | Allied Vision | Model: | fxo532C25GE - fxo532M25GE | Total Pixels: | 16,197,120 |
| Resolution: | 5328 (h) 3040 (v) | Sensor Size: | 1.1" | Color/B & W: | Color / Monochrome |
| Frame Rate (fps): | 144 | Sensor Type: | CMOS | Sensor Device: | Sony IMX532 |
| Pixel Size(µm): | 2.74(h) 2.74(v) | A/D Bits: | 12 | Shutter Speed: | 4µs to 60 s |
| Interface: | 25GigE | Voltage(VDC): | 10 to 25VDC | Power(watts): | 17.5 W |
| Lens Mount: | C | Shutter Type: | Global | Weight(grams): | 320 |
| S/N Ratio(dB): | call | External Trigger: | Yes | Dimensions(mm): | 100Lx50Wx50H |
