Allied Vision fxo425C25GE | fxo425M25GE
The Allied Vision fxo425C25GE (Color) and fxo425M25GE (Monochrome) 25GigE camera features a Sony Pregius S IMX425 1.1" CMOS global shutter sensor with 1.8 megapixel (1600x1104 resolution), maximum 671 frame rate, and a 9 µm pixel size.
Allied Vision FXO GigE cameras combine advanced Sony Pregius S sensors with ultra-high-speed Ethernet connectivity to deliver exceptional image quality, fast data transfer, and reliable performance, providing a flexible and scalable imaging platform for next-generation machine vision systems. These GigE Vision and GenICam compliant FXO cameras are available with 10GigE, 25GigE, or 100GigE interfaces, and color, monochrome, or SWIR configurations.
FXO 10GigE, 25GigE & 100GigE Cameras Features
fxo425C25GE - fxo425M25GE Camera Features
fxo425C25GE (Color) Datasheet
fxo425M25GE (B&W) Datasheet
fxo425C25GE - fxo425M25GE Manual
Sensor Spec
| Manufacturer: | Allied Vision | Model: | fxo425C25GE - fxo425M25GE | Total Pixels: | 1,766,400 |
| Resolution: | 1600 (h) 1104 (v) | Sensor Size: | 1.1" | Color/B & W: | Color / Monochrome |
| Frame Rate (fps): | 671 | Sensor Type: | CMOS | Sensor Device: | Sony IMX425 |
| Pixel Size(µm): | 9(h) 9(v) | A/D Bits: | 12 | Shutter Speed: | 6µs to 60 s |
| Interface: | 25GigE | Voltage(VDC): | 10 to 25VDC | Power(watts): | 17 W |
| Lens Mount: | C | Shutter Type: | Global | Weight(grams): | 320 |
| S/N Ratio(dB): | call | External Trigger: | Yes | Dimensions(mm): | 100Lx50Wx50H |
