Camera Link Area scan camera JAI CV-L107CL JAI CV-L107CL
Camera Link Camera
Proprietary Sensor
2048x3 Resolution
Area Scan Camera


CV-L107CL is discontinued. Please contact us as we may have a few left in stock.

Our sales engineers can help you in selecting a replacement camera. Please provide us with your application details and we will contact you ASAP. You can submit your application and contact details HERE and we will contact you ASAP.

JAI Sweep High Performance Prism based Color Line Scan Cameras Features

  • 512 to 4K, 3CCD/4CCD prism-based for high color precision
  • High performance prism based color line scan cameras
  • Multiple CCD or CMOS line sensors
  • Higher color precision and less color degradation

CV-L107CL Camera Features

  • Very unique 3 CCD line scan
  • Color output
  • Sub pixel alignment between colors using beam splitter technology
  • 3 CCD eliminates off axis imaging artifacts
    • CV-L107CL Datasheet CV-L107CL Manual All JAI Cameras
    Manufacturer: JAI Model: CV-L107CL Total Pixels: 6,144
    Resolution: 2048 (h) 3 (v) Sensor Size: 29mm Color/B & W: Color
    Frame Rate (fps): 19 Sensor Type: CCD Sensor Device: Proprietary
    Pixel Size(µm): 14(h) 14(v) A/D Bits: 10 Shutter Speed: call
    Interface: Camera Link Voltage(VDC): 12V Power(watts): 15
    Lens Mount: F Shutter Type: Global Weight(grams): 860
    S/N Ratio(dB): call External Trigger: YES Dimensions(mm): 90Lx90Wx90H

    JAI Camera Resources


    click to calculate FOV/FL for this camera

    Lens Calculator



    Click to see our wide selection of camera accessories
    Camera Accessories
